SHACMAN X3000 8X4 Heavy Dump Truck 420HP with Euro III Emission Standard

Product Details

Highlight:

420HP Heavy Dump Truck

8X4 Drive Dump Truck

Euro III Emission Tipper Truck

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

T/T

RELATED PRODUCTS

Contact Now

Product Description

SHACMAN X3000 8X4 Dump Trucks 420HP

Vehicle Specifications

Model	SX33156V366C
Drive Type	8X4
Wheelbase	1800+3575+1400 mm
Speed Range	40-55 km/h (Economic) / 75 km/h (Maximum)
Gross Vehicle Weight	≤70 Tons

Engine System

Model	ISME420 30 (JACOB)
Horsepower	420 HP
Emission Standards	Euro Ⅲ

Transmission & Drivetrain

Gear Box Brand	FAST
Gear Box Model	12JSD200T-B Iron Shell with QH50 Power Take-Off + FHB400 Retarder
Chassis Dimensions	850*300 mm (8+7)

Suspension System

Front: Multi-leaf springs (four main pieces and four horses)
Rear: Multi-leaf springs (four main pieces and four horses)

Axle Configuration

Brand	HANDE
Front Axle	9.5T front axle HD technology
Rear Axle	2*16T HD technology with differential lock between wheels
Speed Ratio	5.92

Tires & Fuel System

Tire Type	13R22.5
Fuel Tank Capacity	400L aluminum alloy fuel tank

Cab Features & Equipment

X3000 medium-length flat-top cab without roof deflector
Hydraulic main seat with ordinary rearview mirror
Electronically controlled automatic climate control air conditioning
Electric window shaker with manual flip mechanism
Metal bumper with light guard and three-stage boarding pedal
Oil bath air filter with normal exhaust system
SHACMAN Telematics (terminal only) with imported clutch
Water tank protection grille with rear stabilizer bar
Taillight protection grille and 180Ah maintenance-free battery
Four-point hydraulic suspension system
WABCO six-channel ABS with iron gas reservoir
Reversing buzzer and 2kg fire extinguisher
LED daytime running lights with E-mark certified components
Jacksell technology compressor
Luxury version on-board tool box
Engine intake heating function

Cargo Box Specifications

Dimensions: 7400*2300*1200 mm
Volume: 20 m³
Material: Q355 manganese plate (bottom 10mm, side 8mm)
Lift Mechanism: Domestic cylinder, front lift system
