Name: SHACMAN F3000 6x4 Tipper Truck 375HP Euro V White
Brand: SHAAN XI HAN OCEAN CO . , LTD
SKU: F3000
Price: 1,000.00 USD
Availability: InStock

Home > products > Heavy Dump Truck >

SHACMAN F3000 6x4 Tipper Truck 375HP Euro V White

SHACMAN F3000 6x4 tipper truck

375HP heavy dump truck

Euro V white tipper truck

Place of Origin:

Shaanxi,Xian

Brand Name:

SHACMAN

Certification:

ISO 9001/CCC

Model Number:

F3000

Request A Quote

Product Details

Modle:

SX3258DT384-white Color

Engine:

WP12.375E50

Transmission:

10JSD180+QH50

Axle:

9.5T /2*16 T Double-stage,speed Ratio-5.92

Wheel Base:

3575+1400 Mm

Tire:

12.00R20

Fuel Tank:

300L

Clutch:

φ430 Diaphragm Spring Clutch

Air Inlet:

Ordinary Air Filter

Chassis:

850×300（8+7）

Suspension:

Front /rear Multi-layer Plate Spring 4 Main Plates + 4 U-shaped Bolts

Cabin:

Medium-length Flat Top

Color:

Neon Red/Green Mountain Green/Star And Moon Blue/Aurora White/Klein Blue/Brandy

Highlight:

SHACMAN F3000 6x4 tipper truck

375HP heavy dump truck

Euro V white tipper truck

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiation

Packaging Details

Nude pack, with wax before shipment.

Delivery Time

45 working days

Payment Terms

T/T,L/C

Supply Ability

5000 units/month

RELATED PRODUCTS

Contact Now

Product Description

SHACMAN F3000 6x4 Tipper Truck 375HP Euro V White

Product Specifications

Attribute	Value
Model	SX3258DT384-white color
Engine	WP12.375E50
Transmission	10JSD180+QH50
Axle	9.5T /2*16 T Double-stage, speed ratio-5.92
Wheel base	3575+1400 mm
Tire	12.00R20
Fuel tank	300L
Clutch	φ430 Diaphragm spring clutch
Air inlet	Ordinary air filter
Chassis	850×300（8+7）
Suspension	Front /rear Multi-layer plate spring 4 main plates + 4 U-shaped bolts
Cabin	Medium-length flat top
Color	Neon Red/Green Mountain Green/Star and Moon Blue/Aurora White/Klein Blue/Brandy

Detailed Product Description

Model: SX3258DT384

Drive type: 6x4

Weight: Gross Vehicle Weight≤50

Engine Brand: WEICHAI

Engine Model: WP12.375E50

Engine Power: 276kw / 375Hp

Gear box Brand: FAST

Gear box Model: 10JSD180+QH50

Dump Truck Parameters

Model	SX3258DT384
Drive type	6x4
Weight	Gross Vehicle Weight ≤50
Dimensions	Wheelbase/(mm) 3775+1400
Performance	Maximum speed/(km/h) 40～55/75 Ground clearance >314
Engine	Brand: WEICHAI Model: WP12.375E50 Power: 276kw / 375Hp Maximum torque: 1650 N*M Displacement: 9.726 L Emission standard: Euro V
Gear box	Brand: FAST Model: 10JSD180+QH50
Clutch	Type: φ430 Diaphragm spring clutch
Cooling	Type: Domestic heat sink
Air inlet	Type: Ordinary air filter
Brakes	Type: Drum brake Service brake: Double circuit air brake Park brake: Rear wheel spring brake Auxiliary brake: WEVB engine exhaust brake
Steering	Type: ZF8098 technology, circulating ball steering machine
Chassis	Type: Parallel trapezoidal frame with variable section Dimensions: 850×300(8+7)
Suspension	Front: Multi-layered leaf springs with 4 Main springs+4 U Bolts Rear: Multi-layered leaf springs with 4 Main springs+4 U Bolts
Axles	Brand: HANDE Front axle: 9.5T front axle MAN technology Rear axle: 16T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 5.92
Tires	Type: 12.00R20
Fuel tank	Tank capacity: 300L Aluminum tank
Electrics	Type: 24V Battery: 165Ah Maintenance-free battery
Cab	Type: SHACMAN F3000 Medium-length flat cab Equipment: Hydraulic main seat, four-point hydraulic suspension cab, ordinary rearview mirror, electronically controlled automatic constant temperature air conditioner, electric window shaker, 165Ah maintenance-free Battery, SHACMAN logo, full English logo.

Key Advantages

F3000 is designed with an improved driver's cab utilizing advanced technologies from the German truck giant, MAN. Spacious, comfortable and safe, the F3000 cab will bring a peace of mind to you on the job.
Frame type structure, local strengthening design, for maximum safety
Industry leading torsional stiffness and bending stiffness
Highly efficient cabin design; reducing drag and increasing air intake to the engine
Toughened laminated windshield glass, ensuring safe operation
Greater driver field of vision; allowing better driver awareness
Spacious interior and storage space, up to 620mm wide cushioned bed

Product Images

Frequently Asked Questions

1. Who are we?

We are based in Shaanxi, China, start from 2015, sell to Africa (70.00%), Southeast Asia (10.00%), Central America (10.00%), South America (4.00%), Mid East (2.00%), Eastern Asia (2.00%), South Asia (2.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production; Always final Inspection before shipment.

3. What can you buy from us?

Dump truck, track truck, lorry truck, Van truck, Mixer truck.

4. What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, CIP, DDU; Accepted Payment Currency: USD, EUR, CNY; Accepted Payment Type: T/T, L/C, D/P D/A Language Spoken: English, French
