Name: SHACMAN F3000 6x4 340hp Crane Cargo Truck with 400L Fuel Tank and 12.00R20 Tires
Brand: SHAAN XI HAN OCEAN CO . , LTD
SKU: H3000
Price: 2,517.00 USD
Availability: InStock

Home > Products > Crane Cargo Truck >

SHACMAN F3000 6x4 340hp Crane Cargo Truck with 400L Fuel Tank and 12.00R20 Tires

6x4 SHACMAN F3000

Cargo Box Truck SHACMAN F3000

340hp SHACMAN F3000

Place of Origin:

Shaanxi, Xian

Brand Name:

SHACMAN

Certification:

ISO 9001/CCC

Model Number:

H3000

Request A Quote

SHACMAN F3000 6x4 340hp Crane Cargo Truck with 400L Fuel Tank and 12.00R20 Tires

Product Details

Modle:

SX5315JSQMT456

Engine:

WP10.340E22

Transmission:

10JSD180+QH50

Axle:

9.5T /2*16 T Double-stage

Wheel Base:

5575+1400

Tire:

12.00R20

Fuel Tank:

400L

Clutch:

φ430 Diaphragm Spring Clutch

Air Inlet:

Ordinary Air Filter

Chassis:

850×300(8+5)

Suspension:

Front /rear Multi-layer Plate Spring 2 Main Plates + 2 U-shaped Bolts

Cabin:

Medium-length Flat Roof

Color:

Neon Red/Green Mountain Green/Star And Moon Blue/Aurora White/Klein Blue/Brandy

Highlight:

6x4 SHACMAN F3000

Cargo Box Truck SHACMAN F3000

340hp SHACMAN F3000

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiation

Packaging Details

Nude pack, with wax before shipment.

Delivery Time

45 working days

Payment Terms

T/T, L/C

Supply Ability

5000 units/month

RELATED PRODUCTS

Contact Now

Product Description

SHACMAN F3000 Crane Cargo Truck 6x4 340hp Cargo Box Truck EuroII

Detailed Product Description

Model: SX1255DR564
Drive type: 6x4
Weight: Gross Vehicle Weight ≤35
Engine Brand: WEICHAI
Engine Model: WP10.340E22
Engine Power: 250kw / 340Hp
Gearbox Brand: FAST
Gearbox Model: 10JSD180

Van Cargo Truck Parameters

Model	SX5315JSQMT456
Drive type	6x4
Weight	Gross Vehicle Weight ≤35
Dimensions	Wheelbase/(mm) 5575+1400
Performance	Maximum speed/(km/h) 50～65/90
Ground clearance	>314
Engine Brand	WEICHAI
Engine Model	WP10.340E22
Power/(kw/HP)	250 kw / 340Hp
Maximum torque / (N.M)/rpm	1600N.m
Displacement/(L)	9.726 L
Emission standard	Euro/ II
Gear box Brand	FAST
Gear box Model	10JSD180
Clutch Type	φ430 Diaphragm spring clutch
Cooling Type	Domestic heat sink
Air inlet Type	Ordinary air filter
Brakes Type	Drum brake
Service brake	Double circuit air brake
Park brake	Rear wheel spring brake
Auxiliary brake	WEVB engine exhaust brake
Steering Type	ZF8098 technology, circulating ball steering machine
Chassis Type	Parallel trapezoidal frame with variable section
Dimensions/(mm)	850×300(8+5)
Suspension Front	Multi-layer plate spring 2 main plates + 2 U-shaped bolts
Suspension Rear	Multi-layer plate spring 2 main plates + 2 U-shaped bolts
Axles Brand	HANDE
Front axle	7.5T front axle MAN technology
Rear axle	13T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 4.769
Tires Type	12.00R20
Fuel tank capacity/(L)	400L Aluminum tank
Electrics Type	24V
Battery	165Ah Maintenance-free battery
Cab Type	SHACMAN F3000 Medium-length flat cab
Cab Equipment	Hydraulic main seat, four-point hydraulic suspension cab, manual window crank, ordinary rear-view mirror, F3000 cooling system, square muffler, 165Ah maintenance-free battery, SHACMAN logo, full English logo.

Overview

Engine: Powered by a robust 340 horsepower (Hp) Euro II engine, the truck delivers reliable performance for hauling goods across different terrains and road conditions.
Chassis: The 6x4 configuration indicates a three-axle setup, with power being delivered to all six wheels. This setup provides enhanced load-carrying capacity, stability, and traction, making it well-suited for medium to heavy-duty cargo transportation.
Van Body: The truck features a covered van body finished in white, offering weatherproof and secure transportation for various types of goods. The van body design and dimensions can be customized based on specific cargo requirements.

Frequently Asked Questions

1. Who are we?

We are based in Shaanxi, China, start from 2015, sell to Africa (70.00%), Southeast Asia (10.00%), Central America (10.00%), South America (4.00%), Mid East (2.00%), Eastern Asia (2.00%), South Asia (2.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production. Always final Inspection before shipment.

3. What can you buy from us?

Dump truck, track truck, lorry truck, Van truck, Mixer truck.

4. What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, CIP, DDU；
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A
Language Spoken: English, French
